Timber Bundle

€1.460,00
bez DPH

Subscription license

One license per Tekla Structures user.

License: Yearly

Timber construction and production in Tekla Structures at your fingertips

The Timber Bundle contains the full range of plugins and extensions to model timber at ease and export it to the majority of production machines common in the timber industry. Next to that it is also provided with a complete set of drawings for parts and assemblies, traditional material and assembly lists, settings for the organizer and on top of that a complete material, profile and bolt/screw database. So all in one, the complete set you need to model and produce timber with Tekla Structures.

Read more
Included extensions

TCS Arrange Views In Drawings (ML147), CS BTL Export (ML019), CS BVN Export (ML081), CS CLT Lamella Visualizer m186, CS Codes to profiles (ML052), CS Combine contour plates m177, CS Convert Plate m173, CS Convert profile to plates Net m094, CS Create Curve Net m119, CS Create Multiple Sections In Drawings (DR004), CS BVX Export (ML027), CS Saw And Bevel Angles To UDA (ML069), CS Detail Numbering Net m135,CS Distance (ML030), CS DXF Export (ML184), CS Electra sockets Net m083, CS Entity Cleanup (ML163), CS Flip (ML029), CS Generate window frame Net m054, CS GT Framing Machine Export (ML053), CS HM Export (ML031), CS Matrix Exchange (ML033),CS Online Panel, CS Pack and Go m161, CS Part cut m044, CS Plate Cutter Export (ML179), CS Randek export (ML077), CS Reporting (ML112), CS Roof along contour plate m065, CS Roof generator Net m072, CS Roof plates Net m024, CS Roof window m064, CS Saw Report (ML012), CS Sequence Tool And Truck Load (ML013), CS Sunken Bolts m096, CS TIGERSTOP Export (ML100), CS Timber Lift Tool m183, CS Timber Percentage m166, CS Timber Process Definer Net m101, CS Timber Process Generator Net m128, CS Timber Roof Panel Net m025, CS TO Arch Cut Net m159, CS TO Contour m149, CS TO Dovetail Tenon And Mortise Net j151, CS TO Girt Shoulder d182,CS TO Housing d102, CS TO Lap Joint Net j152, CS TO Marking Net m116, CS TO Profile contour d142, CS TO Ridge Cut Valley Cut d153, CS TO Roof Overhang d084, CS TO Swallow Tenon And Mortise Net j158, CS TO Tenon And Mortise Net j150, CS_Visualizer,CS Wood frame window-door m058, CS Wood wall m057, CS Wood wall on panel Net m082, CS Wooden roof m063, CS WUP Export (ML134).
Specifications
  • Tekla Structures 2025 or higher
  • Tekla Structures Diamond or Trial license
  • Construsoft Tekla Extensions licenses are valid for one full month or year (depending on the chosen interval).
  • Construsoft Tekla Extensions licenses are renewed automatically, unless deactivated in the Construsoft shop account environment before the renewal date.
  • The licenses will be active for use within an hour after the moment of buying.
System requirements
License: Yearly

Need to model Timber in Tekla Structures?

With the Timber Bundle you can do this with ease. All you need to do is get your License. A Tekla Structures License is needed, Diamond, Educational or Trial. The Timber Bundle works on Tekla Structures 2025 and higher.

Exports

To export the modeled beams and sheets we have dedicated export extensions for Hundegger (BVX and BVN), Weinmann Assembly machines (WUP), TigerStop, H&M and generic plate cutter machines that use Ardis.

For beam and sheet processing machines from Homag, Weinmann, H&M, SCM, MBA, Graule, Stromab, Biesse, Reichenbacher and more we have the BTL Export extension.

Timber Frames

For efficient modeling of timber frame walls, floors and roofs we have the Wood wall plugin and Sloping Roof plugin.

CLT walls can be modeled with the Tekla Wall and Floor Layout plugin, when you combine this with our predefined CLT materials and the CLT Lamella visualizer plugin you create outstanding CLT parts.

Traditional Timber

For the traditional timber constructions, we have a wide range of plugins for easy modeling and all work neatly together with our export extensions.

And there are many extensions and properties to extract even more information from the modeled parts.

Environment

To complete the process, the Timber International environment contains a full set of drawings for Timber Wall, Floor and Roof frame assemblies and of course CLT parts and assemblies. And we did not forget the Timber beams and plates, for them there is also a set of drawings.

Reports

On top of that, we have defined multiple lists and reports for assemblies and parts. And if you prefer to use the Organizer, the most common categories and object browser settings are there for you.

Frequently asked questions about the Timber Bundle

Is the license per user?

Yes, the license is per user per year.
What is included in the Timber Bundle?

A selection of what comes with the Timber Bundle:
- To export the modeled beams and sheets we have dedicated export extensions for Hundegger (BVX and BVN), Weinmann Assembly machines (WUP), TigerStop, H&M and generic plate cutter machines that use Ardis.
- For beam- and sheet processing machines from Homag, Weinmann, H&M, SCM, MBA, Graule, Stromab, Biesse, Reichenbacher and more we have the BTL Export extension.
- For efficient modeling of timber frame walls, floors and roofs we have the Wood wall plugin and Sloping Roof plugin.
- CLT walls can be modeled with the Tekla Wall and Floor Layout plugin, when you combine this with our predefined CLT materials and the CLT Lamella visualizer plugin you create outstanding CLT parts.
- For the traditional timber constructions, we have a wide range of plugins for easy modeling and all work neatly together with our export extensions.

And there are many extensions and properties to extract even more information from the modeled parts.

To complete the process, the Timber International environment contains a full set of drawings for Timber Wall, Floor and Roof frame assemblies and of course CLT parts and assemblies. And we did not forget the Timber beams and plates, for them there is also a set of drawings.

On top of that, we have defined multiple lists and reports for assemblies and parts. And if you prefer to use the Organizer, the most common categories and object browser settings are there for you.
Do you have courses available?

Yes, you can find timber courses in the e-learning section of our store.
